Advance Technical Data
IXGH 6N170A
IXGT 6N170A
VCES
IC25
= 1700 V
6 A
High Voltage
IGBT
=
VCE(sat) = 7.0 V
tfi(typ)
=
32 ns
Symbol
TestConditions
Maximum Ratings
TO-268(IXGT)
VCES
VCGR
TJ = 25°C to 150°C
1700
1700
V
TJ = 25°C to 150°C; RGE = 1 MΩ
V
G
VGES
VGEM
Continuous
Transient
20
30
V
V
E
C (TAB)
IC25
IC90
ICM
TC = 25°C
6
3
A
A
A
TO-247AD(IXGH)
TC = 90°C
TC = 25°C, 1 ms
14
SSOA
(RBSOA)
VGE = 15 V, TVJ = 125°C, RG = 33Ω
ICM = 12
@ 0.8 VCES
A
C (TAB)
Clamped inductive load
G
C
E
tSC
PC
TJ = 125°C, VCE = 1200 V; VGE = 15 V, RG = 33Ω
TC = 25°C
10
75
µs
G = Gate,
E=Emitter,
C = Collector,
TAB = Collector
W
TJ
-55 ... +150
150
°C
°C
°C
Features
z International standard packages
JEDEC TO-268 and
TJM
Tstg
-55 ... +150
JEDEC TO-247 AD
Md
Mounting torque (M3)
(TO-247)
1.13/10Nm/lb.in.
300 °C
z High current handling capability
z MOS Gate turn-on
Maximum lead temperature for soldering
1.6 mm (0.062 in.) from case for 10 s
- drive simplicity
z Rugged NPT structure
z Molding epoxies meet UL 94 V-0
flammability classification
Weight
TO-247
TO-268
6
4
g
g
Applications
z Capacitor discharge & pulser circuits
z AC motor speed control
z DC servo and robot drives
z DC choppers
Symbol
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
z Uninterruptible power supplies (UPS)
z Switched-mode and resonant-mode
power supplies
BVCES
VGE(th)
IC = 250 µA, VGE = 0 V
IC = 250 µA, VCE = VGE
1700
3.0
V
V
5.0
ICES
VCE = 0.8 • VCES
VGE = 0 V
TJ = 25°C
Note 1 TJ = 125°C
10
500
µA
µA
Advantages
z High power density
IGES
VCE = 0 V, VGE = 20 V
IC = IC90, VGE = 15 V
100
7.0
nA
z Suitable for surface mounting
z Easy to mount with 1 screw,
(isolated mounting screw hole)
VCE(sat)
TJ = 25°C
TJ = 125°C
5.5
6.5
V
V
