Crystal Units
For OA / AV
NX2016AB
Features
n
A small surface-mount type crystal unit, especially suited for small-sizing
requirements.
Ultra compact and thin. (2.0×1.6×0.±5mm typ., H : 0.4mm Max.℃
l
l
Highly reliable.
Ideal for ultra compact TV tuners.
l
l
Lead-free. Meets the requirements for re-flow profiling using lead-free solder.
Pb
Free
Specifications
n
Model
NX2016AB
Item
Frequency Range
26 to 80MHz
Overtone Order
Fundamental
−6
Frequency Tolerance (25 ±±3℃
±20 × 10
±20 × 10
−6
Temperature Characteristics (with reference to +25°C℃
Operating Temperature Range
Equivalent Series Resistance
Drive Level
−±0 to +753
Refer to *1
10μW(Max:200μW℃
8pF
Load Capacitance
The above specifications are standard for this NDK product.
Custom-made specifications such as load capacitance and temperature characteristics are also available.
Please contact NDK sales with your enquiries.
How to Specify an Order
n
When ordering our products, specify them with an “Ordering Code” that consists of the following :
Model name - Frequency (Max : 9 digits℃ M - Number for specifying an order
Example NX2016AB-26.000M-STD-CSZ-2
If you have any queries concerning our standard frequencies and numbers for specifying orders, please contact our sales representatives or visit our homepage
(http://www.ndk.com/℃.
Dimensions
n
*1 Equivalent Series Resistance
Frequency (MHz℃
Equivalent Series
mm
(Range℃
Resistance max.[Ω]
2.0±0.1
24 to 25
25 to ±6
±6 to 80
100
80
60
Internal connections(TOP VIEW℃
#±
#4
#1
#2
*#2 and #4 are connected with a cover.
Reference land pattern
#1
#4
#2
#±
0.65
0.85
1.±5
1.±5
