IXGK 50N60AU1
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-264 AA Outline
IC = IC90; VCE = 10 V,
25
35
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Qg
200
50
nC
nC
nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
80
Inductive load, TJ = 25°C
td(on)
tri
td(off)
tfi
50
210
200
275
4.8
ns
ns
IC = IC90, VGE = 15 V, L = 100 µH,
VCE = 0.8 VCES, RG = Roff = 2.7 Ω
ns
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
400 ns
mJ
Eoff
td(on)
tri
50
240
3
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V, L = 100 µH
VCE = 0.8 VCES, RG = Roff = 2.7 Ω
Eon
td(off)
tfi
mJ
ns
280
600
9.6
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
ns
Eoff
mJ
RthJC
RthCK
0.42 K/W
K/W
0.15
Reverse Diode (FRED)
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
VF
TestConditions
IF = IC90, VGE = 0 V,
1.7
V
Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
IRM
trr
IF = IC90, VGE = 0 V, -diF/dt = 480 A/µs
VR = 360 V
IF = 1 A; -di/dt = 200 A/µs; VR = 30 V TJ = 25°C
19
175
35
33
50
A
ns
ns
TJ =125°C
RthJC
0.75 K/W
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYS MOSFETS and IGBTs are covered by one or more of the following U.S. patents: 4,835,592 4,881,106
4,850,072 4,931,844
5,017,508
5,034,796
5,049,961 5,187,117 5,486,715
5,063,307 5,237,481 5,381,025
