Single Multi-core MIPS64-based Cavium
OCTEON™ Network Appliance
NCP-3108
NEW
Features
. OCTEON™ MIPS64 processor with 16 cores
. Up to 8 Gigabit Ethernet ports
. Supports one 64-bits/66 MHz PCI-X slot
. Supports one 3.5" SATA HDD or two 2.5" SATA HDD
. Supports security, regular expression and de-/compression engine
RoHS
COMPLIANT
2002/95/EC
Specifications
Processor
Cavium OCTEON CN3860
Max Speed
500 MHz
16
Yes
Yes
Yes
Processor Cores
Encryption Engine
Reg-ex Acceleration
TCP Acceleration
Technology
Processor System
ECC registered DDR2 400/533/667 MHz DIMMs
System Memory
Capacity
Up to 8 GB
Memory Socket
RLDRAM type
Size
Four 240-pin DIMM slots
MT49H32M9BM-33
256 MB
RLDRAM
Flash type
Max Flash size
S29JL064H x 1
8 MB
Boot Flash
Option I.
Eight 100/1000 Base T Gigabit Ethernet Ports.
Option II.
Networking Interface
Ethernet Port
Four 100/1000 Base T Gigabit Ethernet Ports
Four SFP connectors.
Expansion
PCI-X Slot
One 64-bits/66 MHz PCI-X Slot
Controller
Silicon Image Sil3124-II SATA PCI 64-bits/66 MHz
Storage System
Storage Interface
Compact Flash Socket
Serial Port
One 3.5" SATA HDD Bay or two 2.5" SATA HDD Bay
1CF socket typeII
1 x DB9 RS-232
USB
LCM Module
2
1
Peripheral
16 x LAN activity and connection
3 x Power, HDD and system status
Notification LED
Type/Watt
Input
AC: Zippy H1U-6250P 250 W/DC: DP1A-6251F
AC 100 ~ 264 Vac Full Range/DC -36 ~ -72 VDC (-48 V normal)
Power
CPU Heatsink
Fan
Passive copper fin heatsink with heatpipe
2
Cooling
Dimension (W x D x H)
Weight
426 x 403.6 x 44 mm (16.8" x 15.9" x 1.7")
8 KG
Physical Characteristics
Temperature: 0 to 40° C
Humidity: 20 % to 90 % RH
Operating
Environment
Temperature: -20 to 70° C
Humidity: 5% to 95 % RH
Non-Operating
