IXGH 10N100
IXGH 10N100A
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-247 AD Outline
IC = IC90; VCE = 10 V,
4
8
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Cies
Coes
Cres
750
150
30
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
Qg
52
13
24
70 nC
25 nC
45 nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
Inductive load, TJ = 25°C
td(on)
tri
td(off)
tfi
100
200
550
ns
ns
1 = Gate
2 = Collector
3 = Emitter
Tab = Collector
IC = IC90, VGE = 15 V, L = 300 µH,
VCE = 0.8 VCES, RG = Roff = 150 Ω
900 ns
Remarks: Switching times
may increase
for VCE (Clamp) > 0.8 • VCES
10N100
10N100A
800
500
ns
ns
,
Eoff
10N100A
2
3
mJ
higher TJ or increased RG
td(on)
tri
100
200
1.1
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V, L = 300 µH
Eon
td(off)
tfi
mJ
VCE = 0.8 VCES, RG = Roff = 150 Ω
600 1000 ns
Remarks: Switching times
may increase
10N100
10N100A
1250 2000 ns
950 1000 ns
for VCE (Clamp) > 0.8 • VCES
higher TJ or increased RG
,
Eoff
10N100
10N100A
5.0
2.5
mJ
mJ
RthJC
RthCK
1.2 K/W
K/W
0.25
IXGH 10N100 and IXGH 10N100A characteristic curves are located on the
IXGH 10N100U1 and IXGH 10N100AU1 data sheets.
IXYS reserves the right to change limits, test conditions, and dimensions.
