Marvell PXA90x Cellular Processor
Stacked Memory
TX
RX
Intel®
Micro Signal
Architecture
RF
Marvell
PXA90x Core
Transceiver
Intel® Flash
32 Mbit
Intel® Flash
4 Mbit
Intel® Analog
Front End
SRAM
2 Mbit
SRAM
1 Mbit
GSM/GPRS Logic
Power
Management
WCDMA Logic
Peripherals
SIM
FEATURES
BENEFITS
•
Intel XScale® Technology
•
Designed to provide optimized power consumption and high-performance
processing for a wide range of wireless and networking applications.
•
•
ARM-Compliant Architecture
Intel Micro Signal Architecture
•
•
The ARM-compliant nature of the XScale core allows already compliant,
existing ARM-based applications to be ported quickly to the PXA90x.
Incorporates both Digital Signal Processing (DSP) and microcontroller
functionality in a single core, delivering significant improvements in
performance, programmability, and power consumption over traditional
DSP designs.
•
Integrated SRAM and Flash Memory
•
Integrated SRAM provides local memory for the system OS, cellular
communications stack, and user applications code. Single bit-per-cell
NOR Flash stores handset firmware and user applications, and enables
execution-in-place (XIP) for code stored on-chip.
•
•
Dual-Mode Modem
•
•
Supports both WCDMA and GSM/GPRS cellular standards with
Dual-RAT capability.
Full Platform Solution
Proven RF, mixed-signal, and PMIC solutions extensively validated
as a unified platform. Proven third-party software solutions enable
a compelling end-user experience.
•
•
Intel Integrated Performance Primitives
Full Range of Support Tools
•
•
Provides pre-optimized multimedia application codecs and libraries to
enable rapid application development and integration, while providing a
compelling end-user experience for advanced applications.
Includes compilers, debuggers, and simulation tools to optimize
performance and speed up TTM.
THE MARVELL ADVANTAGE: Marvell products come with complete reference designs which include board layout designs, software, manufacturing
diagnostic tools, documentation, and other items to assist customers with product evaluation and production. Marvell’s worldwide field application
engineers collaborate closely with end customers to develop and deliver new leading-edge products for quick time-to-market. Marvell utilizes world-
leading semiconductor foundry and packaging services to reliably deliver high-volume and low-cost total solutions.
ABOUT MARVELL: Marvell is the leader in storage, communications and consumer silicon solutions. Marvell’s diverse product portfolio includes
switching, transceiver, communications controller, processors, wireless, power management and storage solutions that power the entire communications
infrastructure, including enterprise, metro, home, and storage networking. Today’s cell phone and handheld users demand the latest and greatest in
mobile functionality. From full-color displays and voice recognition to video streaming and Bluetooth capabilities, Marvell cellular and applications
processors deliver full-featured, media-rich experiences to the palm of your hand. Based on the Intel® XScale micro-architecture, Marvell’s cellular
and applications processors feature advanced integration, multimedia acceleration, and superior power savings that propel the evolution of mobile
devices. For more information, visit our website at www.marvell.com.
