Part No.
QTCM-1KPSIG-D
QTCM manifold, 1KPSIG digital gauge kit
Perform static pressure calibrations using
nitrogen with included calibration manifold,
pressure gauge and hoses
Features
Item Includes
•
•
•
Assembly - QTCM Assembly (QTCM)
Gauge - 0-1000 psig Digital Pressure Gauge (GAUD-1000)
Gauge Adapter - 1/4" female NPT x female QT, no check-
valve, brass (QTHA-2FBA)
•
•
•
•
Hose - Quick-test hose, brass hose ends, 20 ft (6.10 m) long
(QTQT-HOS-20ft)
Hose - Quick-test hose, brass hose ends, 2 ft (61 cm) long
(QTQT-HOS-2ft)
QTCM-1KPSIG-D
Hose Adapter - 1/4" male NPT x male QT, no check-valve,
brass (QTHA-2MB0)
Hose Adapter - 1/4" male NPT x male QT, no check-valve,
brass (QTHA-2MB0)
Specifications
Pressure Range
0 to 3000 psi (0 to 207 bar)
0 to 1000 psig
Gauge Pressure Range
Temperature range
0 to 130 °F (-18 to 54 °C)
Gauge Temperature range -4 to 185 °F (-20 to 85 °C)
Construction
Seal materials
Weight
Brass
Buna-N, Delrin, Teflon
2.71 lb (1.2 kg)
Dimensions
H: 7.88 in (20.02 cm) x W: 5 in (12.70 cm) x D: 3.78 in (9.60 cm)
Ralston Instruments Inc. | ralstoninst.com | Toll Free 800-347-6575 | Phone 440-564-1430 | Fax 440-564-1480
