SMD Type
Diodes
PIN Diode for VHF,UHF,AGC USE Applications
1SV234
SOT-23
Unit: mm
+0.1
2.9
-0.1
+0.1
0.4
-0.1
Features
3
Series connection of 2 elements in an ultrasmall package facilitates high-density
mounting and permits 1SV234-applied equipment to be made smaller.
Small interterminal capacitance (C=0.23pF typ).
1
2
+0.1
0.95
-0.1
+0.05
0.1
-0.01
Small forward series resistance (rs=5 typ).
+0.1
1.9
-0.1
1.Base
2.Emitter
3.collector
Absolute Maxim um Ratings Ta = 25
Parameter
Reverse Voltage
Symbol
Value
50
Unit
V
VR
IF
Forward Current
50
mA
mW
Allowable Power Dissipation
Junction Temperature
Storage temperature
P
150
Tj
125
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
Conditions
IR = 10
Min
50
Typ
Max
0.1
Unit
V
VR
IR
A
Reverse Current
VR = 50 V
IF = 50 mA
A
Forward Voltage
VF
C
0.95
0.23
5
V
Interterminal Capacitance
Series Resistance
VR = 50 V, f = 1 MHz
pF
rs
IF = 10 mA,f = 100 MHz
Note:The specifications shown above are for each individual diode
Marking
Marking
CV
1
