SMD Type
Diodes
VHF~UHF Band RF Attenuator Applications
1SV252
Features
Absolute Maximum Ratings Ta = 25
Parameter
Reverse voltage
Symbol
Rating
50
Unit
V
VR
IF
Forward current
50
mA
Junction Temperature
Storage temperature
Tj
125
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
VR
Conditions
Min
50
Typ
Max
Unit
V
IR = 10
A
Reverse Current
Forward voltage
Total capacitance (Note 1)
Series resistance
Note
IR
VR = 50 V
IF = 50 mA
0.1
0.98
0.4
A
VF
0.93
0.2
V
CT
VR = 50 V, f = 1 MHz
pF
rS
IF = 10 mA, f = 100 MHz
3.5
10
1. CT is measured by 3 terminal method with capacitance bridge.
Marking
Marking
BE
1
