Part Number:
Status:
1200905074
Active
nanochange_40m841_products
Overview:
Description:
Nano-Change® (M8) Receptacle, M8 x 0.5 Mounting Threads, Straight Male, Male
Length 0.50m (1.64' ) Length, with 4 Poles on Mating Side
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
Agency Certification
image - Reference only
EU RoHS China RoHS
ELV and RoHS
Compliant
UL
E152210
General
Product Family
Series
Industrial Receptacles
120090
REACH SVHC
Not Reviewed
Halogen-Free
Status
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
nanochange_40m841_products
Nano-Change® (M8)
Single Ended (pigtail)
Not Reviewed
Need more information on product
environmental compliance?
Physical
Coupling Type
Gender
External Thread
Male
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Keyway
Length
Material - Component
Mounting Thread Size
Orientation
None
0.20m (7.87")
Nickel-plated Brass
M8 x 0.5
Straight
Please visit the Contact Us section for any
non-product compliance questions.
Panel Mount
Poles
Back, Front
4
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-25°C to +90°C
24
Leads
Search Parts in this Series
120090Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4A
60V AC / 75V DC
Material Info
Old Part Number
4R4F06E02C200
SD-120090-003
Reference - Drawing Numbers
Sales Drawing
