Part Number:
Status:
1200905076
Active
nanochange_40m841_products
Overview:
Description:
Nano-Change® (M8) Receptacle, M8 x 0.5 Mounting Threads, Straight Female, Male
Length 0.20m (7.87") Length, with 4 Poles on Mating Side
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
General
Product Family
Series
image - Reference only
China RoHS
Industrial Receptacles
120090
IP67
EU RoHS
IP Rating
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
NEMA Rating
Overview
Product Name
Type
NEMA 6
nanochange_40m841_products
Nano-Change® (M8)
Single Ended (pigtail)
Physical
Coupling Type
Gender
Internal Thread
Female
None
Keyway
Length
0.20m (7.87")
Nickel-plated Brass
M8 x 0.5
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Material - Component
Mounting Thread Size
Orientation
Straight
Panel Mount
Poles
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
Back, Front
4
-25°C to +90°C
24
Please visit the Contact Us section for any
non-product compliance questions.
Leads
Search Parts in this Series
120090Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4A
60V AC / 75V DC
Material Info
Old Part Number
4R4F30E02C200
SD-120090-002
Reference - Drawing Numbers
Sales Drawing
