This document was generated on 05/20/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
1200905077
Active
nanochange_40m841_products
Overview:
Description:
Nano-Change® (M8) Receptacle, M8 x 1.0 Mounting Threads, Straight Male, Male with
Back Mounting Pins, with 4 Poles on Mating Side
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
General
Product Family
Series
image - Reference only
China RoHS
Industrial Receptacles
120090
IP67
EU RoHS
IP Rating
RoHS Compliant by
Exemption
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
NEMA Rating
Overview
Product Name
Type
NEMA 6
nanochange_40m841_products
Nano-Change® (M8)
Bulkhead Feed-Through
Physical
Coupling Type
Gender
External Thread
Male
None
Keyway
Length
N/A
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Material - Component
Mounting Thread Size
Orientation
Nickel-plated Brass
M8 x 1.0
Straight
Panel Mount
Poles
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
Back
4
-25°C to +90°C
N/A
N/A
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
120090Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4A
60V AC / 75V DC
Material Info
Old Part Number
4R4F46000
Reference - Drawing Numbers
Sales Drawing
SD-120090-005
This document was generated on 05/20/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
