IXGH 38N60U1
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-247 AD Outline
IC = IC90; VCE = 10 V,
15
20
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Cies
Coes
Cres
2500
270
70
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
Qg
125
23
150 nC
35 nC
75 nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
50
Inductive load, TJ = 25°C
td(on)
tri
td(off)
tfi
30
ns
ns
1 = Gate
2 = Collector
3 = Emitter
Tab = Collector
IC = IC90, VGE = 15 V, L = 100 µH,
VCE = 0.8 VCES, RG = Roff = 10 Ω
150
600 1200 ns
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
500
9
700 ns
15 mJ
Eoff
td(on)
tri
40
160
1
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V, L = 100 µH
VCE = 0.8 VCES, RG = Roff = 10 Ω
Eon
td(off)
tfi
mJ
ns
800
1000
15
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
ns
Eoff
mJ
RthJC
RthCK
0.62 K/W
K/W
0.25
Reverse Diode (FRED)
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
VF
TestConditions
IF = IC90, VGE = 0 V,
1.6
V
Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
IRM
trr
IF = IC90, VGE = 0 V, -diF/dt = 240 A/µs
VR = 360 V
IF = 1 A; -di/dt = 100 A/µs; VR = 30 V TJ = 25°C
10
150
35
15
50
A
ns
ns
TJ =125°C
RthJC
1 K/W
