IXGK80N60A
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
TO-264 AA Outline
min. typ.
max.
IC = 40A; VCE = 10 V,
30
50
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Qg
400
70
nC
nC
nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
160
Cies
Coes
Cres
8000
860
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
200
td(on)
tri
td(off)
tfi
Inductive load, TJ = 25°C
50
210
300
350
ns
ns
ns
ns
IC = IC90, VGE = 15 V, L = 100 µH,
VCE = 0.8 VCES, RG = Roff = 2.7 Ω
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
500
Eoff
10 12.5 mJ
td(on)
tri
50
240
3
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V, L = 100 µH
VCE = 0.8 VCES, RG = Roff = 2.7 Ω
Eon
td(off)
tfi
mJ
ns
400
600
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
ns
Eoff
15
mJ
RthJC
RthCK
0.25 K/W
K/W
0.15
