VZ Series Power MOSFET
N-Channel Enhancement type
OUTLINE DIMENSIONS
2SK2490
( F10F18VZ )
Case : FTO-220
(Unit : mm)
180V 10A
FEATURES
●Input capacitance (Ciss) is small.
Especially, input capacitance
at 0 biass is small.
●The static Rds(on) is small.
●The switching time is fast.
APPLICATION
●DC/DC converters
●Power supplies of DC 12-24V input
●Product related to
Integrated Service Digital Network
RATINGS
●Absolute Maximum Ratings （Tc = 25℃）
Item
Symbol
Conditions
Ratings Unit
-55～150 ℃
150
stg
StorageTemperature
T
T
ch
ChannelTemperature
DSS
Drain-SourceVoltage
V
180
±30
10
20
10
40
10
2
0.5
V
Gate-SourceVoltage
VGSS
D
I
DP
I
S
I
PT
AS
I
ContinuousDrainCurrent（DC）
ContinuousDrainCurrent（Peak)
ContinuousSourceCurrent（DC）
TotalPowerDissipation
SinglePulseAvalancheCurrent
DielectricStrength
A
W
ch
T =25℃
A
kV
N･m
dis
V
Terminalstocase,ꢀAC 1minute
MountingTorque
TOR （Recommendedtorque：0.3 N･m ）
