IN7406
Hex Inverter Buffers/Drivers with
Open-Collector High-Voltage
Outputs
The IN7406 monolithic TTL hex inverter buffers/drivers feature
high-voltage open collector outputs for interfacing with high-level
circuits (such as MOS) or for driving high-current loads (such as lamps
or relays), and are also characterized for use as inverter buffers for
driving TTL inputs.
·
·
·
·
·
Minimum breakdown Voltages is 30 V
Maximum sink Current is 40 mÀ
Converts TTL Voltage Levels to MOS Levels
Open-Collector Driver for Indicator Lamps and Relays
Inputs Fully Compatible with MOST TTL Circuits.
ORDERING INFORMATION
IN7406N Plastic
IN7406D SOIC
IZ7406
Chip
TA = -10° to 70° C
for all packages
PIN ASSIGNMENT
LOGIC DIAGRAM
FUNCTION TABLE
Inputs
Output
A
L
Y
Z
L
H
Z = High Impedance
Y = A
PIN 14 =VCC
PIN 7 = GND
