Part Number:
Status:
1200700121
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) 4 Poles, Front Panel Mount Receptacle, 1/4" - 18 NPT Threads,
Female (Straight) to 22 AWG PVC Leads, 2.0m (6.56') Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
Series image - Reference only
LR6837
E152210
EU ELV
Not Relevant
General
Product Family
Series
Industrial Receptacles
120070
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Contained Per -
ED/30/2017 (7 July
2017)
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
78678831575
Di-(2-
UPC
ethylhexyl)phthalate
(DEHP)
2,4-Di-tert-butyl-6-(5-
chlorobenzotriazol-2-
yl)p
Halogen-Free
Status
Not Reviewed
Physical
Coupling Type
Gender
Keyway
Length
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
Internal Thread
Female
Single
0.305m
Gray Annodized Aluminum
1/4" - 18 NPT
45.650/g
Straight
Front
For more information, please visit Contact US
China ROHS
ELV
Green Image
Not Relevant
4
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-20°C to +80°C
22
UL 1061
RoHS Phthalates
Contained: DEHP
Search Parts in this Series
120070 Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R4A00A18M020
SD-120070-056
Reference - Drawing Numbers
Sales Drawing
