XU1006-QB-0N0T

型号：

XU1006-QB-0N0T

品牌：

MIMIX[ MIMIX BROADBAND ]

页数：

9 页

PDF大小：

257 K

下载PDF手册
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Features
Sub-harmonic, Image Reject Transmitter
Integrated Mixer, LO Doubler/Buffer & Output Amplifier
+17.0 dBm Output Third Order Intercept (OIP3)
+2.0 dBm LO Drive Level
2.0 dB Conversion Gain
7x7mm SMT Package
100% RF and DC Testing
Absolute Maximum Ratings
General Description
Supply Voltage (Vd)
Supply Current (Id)
Gate Bias Voltage (Vg)
Input Power (Pin)
Storage Temperature (Tstg) -65 to +165 deg C
Operating Temperature (Ta) -55 to MTTF Table1
Channel Temperature (Tch) MTTF Table1
+6.0 VDC
Mimix Broadband’s 36.0-42.0 GHz GaAs transmitter has a +17.0 dBm
output third order intercept across the band.This device is a
balanced, resistive pHEMT mixer followed by a distributed output
amplifier and includes an integrated LO doubler and LO buffer
amplifier.The use of integrated LO doubler and LO buffer amplifier
makes the provision of the LO easier than for fundamental mixers at
these frequencies. I and Q mixer inputs are provided and an external
90 degree hybrid is required to select the desired sideband.The
device comes in a 7x7mm SMT package that is RoHS compliant.This
device is well suited for Millimeter-wave Point-to-Point Radio, LMDS,
SATCOM and VSAT applications.
350 mA
+0.3 VDC
+0.0 dBm
ESD - Human Body Model
ESD - Machine Body Model Class M1
Moisture Sensitivity Level MSL3
(1) Channel temperature affects a device’s MTTF. It is
recommended to keep channel temperature as low as
possible for maximum life
Class 1A
Electrical Characteristics (AmbientTemperatureT = 25o C)
Parameter
Frequency Range (RF) Upper Side Band
Frequency Range (RF) Lower Side Band
Frequency Range (LO)
Units
GHz
GHz
GHz
GHz
dB
Min.
36.0
36.0
16.0
DC
-
0.0
+2.0
Typ.
-
-
-
-
10.0
2.0
+4.0
-25.0
-15.0
13.0
28.0
+4.0
-0.3
-0.5
-
Max.
42.0
42.0
26.0
4.0
-
4.0
-
Frequency Range (IF)
Output Return Loss RF (S22)
Small Signal Conversion Gain IF/RF (S21)
LO Input Drive (PLO)
Leakage @ RF Port LOx1
Leakage @ RF Port LOx2
Input Third Order Intercept (IIP3)
Attenuation Range
Drain Bias Voltage (Vd)
dB
dBm
dBm
dBm
dBm
dB
VDC
VDC
VDC
VDC
mA
-
-
-
-12.0
-
-
-
-
-
0.0
-
-
10.0
25.0
-
-
Gate Bias Voltage (Vg1)
Gate Bias Voltage (Vg2) Mixer, Doubler
Dynamic Range Control (Vc)
Supply Current (Id) (Vd=4.0V)
Supply Current (Ic)
-
-2.0
-
-
240
0.0
mA
Page 1 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Transmitter Measurements
XU1006-QB, USB Conv. Gain (dB) and Image Rejection (dBc)
XU1006-QB, LSB Conv. Gain (dB) and Image Rejection (dBc)
10
5
10
5
0
0
Conv Gain
Image Rej
-5
-5
Conv Gain
Image Rej
-10
-15
-20
-25
-10
-15
-20
-25
36
37
38
39
40
41
42
36
37
38
39
40
41
42
RF USB (GHz) [IF=2 GHz]
RF LSB (GHz) [IF=2 GHz]
XU1006-QB, 1xLO to RF Leakage (dBm), P_LO=+2dBm
XU1006-QB, 2xLO to RF Leakage (dBm), P_LO=+2dBm
0
-5
0
-5
-10
-15
-20
-25
-30
-10
-15
-20
-25
-30
17.0
17.5
18.0
18.5
19.0
19.5
20.0
20.5
17.0
17.5
18.0
18.5
19.0
19.5
20.0
20.5
LO (GHz)
LO (GHz)
RFout-2xLO (dBc) vs. LO Freq
P_LO=+2 dBm, IF_in=-10dBm
XU1006-QB, Output IP3 (dBm)
20
18
16
14
12
10
8
25
20
15
10
5
6
4
USB
LSB
2
0
0
17.0
17.5
18.0
18.5
19.0
19.5
20.0
20.5
36
37
38
39
40
41
42
LO Freq (GHz)
RF (GHz)
Page 2 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Transmitter Measurements (cont.)
XU1006-QB, Input IP3 (dBm)
18
XU1006-QB, Conv Gain and IIP3 vs Vc (Dynamic Range)
RF=38GHz, IF=2GHz, P_IF=-3dBm/tone
20
16
14
12
10
8
15
10
5
0
-5
-10
-15
-20
-25
-30
6
CG @ USB
CG @ LSB
IIP3 @ USB
IIP3 @ LSB
4
USB
LSB
2
0
36
37
38
39
RF (GHz)
40
41
42
-2.0
-1.8
-1.6
-1.4
-1.2
-1.0
-0.8
-0.6
-0.4
-0.2
0.0
Vc (V)
USB Conversion Gain Vs Control Voltage (Vc), 38GHz
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm
USB Conversion Gain Vs Control Voltage (Vc), 36GHz
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm
20
15
10
5
20
15
10
5
0
0
-5
-5
-10
-15
-20
-25
-30
-10
-15
-20
-25
-30
40ºC
Conv Gain,36 GHz,Temp=-
Conv Gain,38 GHz,Temp=-40ºC
Conv Gain,36 GHz,Temp=+25ºC
Conv Gain,36 GHz,Temp=+75ºC
GHz,Temp=+25ºC
Conv Gain,38
Conv Gain,38 GHz,Temp=+75ºC
-2
-1.8
-1.6
-1.4
-1.2
-1
-0.8
-0.6
-0.4
-0.2
0
-2
-1.8
-1.6
-1.4
-1.2
-1
-0.8
-0.6
-0.4
-0.2
0
Vc (V)
Vc (V)
LSB IIP3 for XU1006-QB
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm, P_IF/tone=-5dBm, ?F=10 MHz
USB IIP3 for XU1006-QB
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm, P_IF/tone=-5dBm, ?F=10 MHz
20
20
18
16
14
12
10
8
18
16
14
12
10
8
IIP3 Temp=-40ºC
Temp=+25ºC
6
6
IIP3
IIP3 Temp=+75ºC
IIP3 Temp=-40ºC
IIP3
IIP3
Temp=+25ºC
Temp=+75ºC
4
4
2
2
0
0
36
37
38
39
40
41
42
36
37
38
39
40
41
42
Frequency (GHz)
Frequency (GHz)
Page 3 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Transmitter Measurements (cont.)
(x2)LO Leakage for XU1006-QB
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm, P_IF=-10dBm, IF_Frequency=2 GHz
LSB Conversion Gain (dB) and IR (dBc) for XU1006-QB
Vg2=-0.5V, Vd=4V, Id=240mA, P_LO=+4dBm, P_IF=-10dBm, IF_Frequency=2 GHz
10
20
15
10
5
5
0
0
-5
-5
-10
-15
-20
-25
-30
Con.Gain Temp=-40ºC
Con.Gain Temp=+25ºC
Con.Gain Temp=+75ºC
IR Temp=-40ºC
-10
IR Temp=+25ºC
IR Temp=+75ºC
x2LO Leakage Temp=-40ºC
-15
-20
x2LO Leakage Temp=+25ºC
x2LO Leakage Temp=+75ºC
36
37
38
39
40
41
42
36
37
38
39
40
41
42
Frequency (GHz)
Frequency (GHz)
USB Conversion Gain (dB) and IR (dBc) for XU1006-QB
g2=-0.V5V, Vd=4V, Id=240mA, P_LO=+4dBm, P_IF=-10dBm, IF_Frequency=2 GHz
20
Con.Gain Temp=-40ºC
Con.Gain Temp=+25ºC
15
Con.Gain Temp=+75ºC
IR Temp=-40ºC
10
IR Temp=+25ºC
IR Temp=+75ºC
5
0
-5
-10
-15
-20
-25
-30
36
37
38
39
40
41
42
Frequency (GHz)
Page 4 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Physical Dimensions
QB - MSL, Gross LeakTest Compliant
Functional Schematic
Package Pin-outTable
GND
GND
VD
IF1
Pin Number
Pin
Name
Pin Function
Nominal
Value
Unit
28
27
26
25
24
23
22
4
RF Out RF Out
7
8
9
11
18
25
27
VC
Gain Control
-2.0 to 0.0 Volts
21
1
VG1
VG2
IF2
LO IN
IF1
LNA, LO Amp
Mixer, Doubler
IF2 Input
LO Input
IF1 Input
-0.4
-0.5
volts
volts
20
19
18
2
3
4
5
6
+2.0
+4.0
dBm
volts
GND
GND
Balanced
LO
Buffer
PA
VD1
Drain Bias
Ground
x2
RF OUT
Reject
Mixer
LO IN
All other pins GND
GND
VC
17
16
15
GND
Zin >> 1M
600
7
12.1 K
8
9
10
11
12
GND
13
14
IF2
VG1 VG2 GND
Page 5 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
Recommended Layout
Environmental
MSL - Gross Test Leak Compliant
Page 6 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
App Note [1] Biasing - App Note [1] Biasing - The device is operated by biasing VD=4.0V with ID=240mA. Additionally, a mixer and doubler
bias are also required with VG2 = -0.5V. Adjusting Vg2 above or below this value can adversely affect conversion gain, image rejection and
intercept point performance.The VC bias pin controls an integrated attenuator where VC=-1.3 V provides the minimum attenuation and
VC = 0.0 V provides the maximum attenuation (approximately 25 dB).
It is recommended to use active biasing to keep the currents constant as the RF power and temperature vary; this gives the most
reproducible results. Depending on the supply voltage available and the power dissipation constraints, the bias circuit may be a single
transistor or a low power operational amplifier, with a low value resistor in series with the drain supply used to sense the current.The gate of
the pHEMT is controlled to maintain correct drain current and thus drain voltage.The typical gate voltage needed to do this is VG1= -0.4V.
Typically the gate is protected with Silicon diodes to limit the applied voltage. Also, make sure to sequence the applied voltage to ensure
negative gate bias is available before applying the positive drain supply.
MTTF
MTTF is calculated from accelerated life-time data of single devices and assumes an isothermal back-plate.
XU1006-QB, MTTF (yrs) vs. Backplate Temperature (°C)
1.0E+05
1.0E+04
1.0E+03
1.0E+02
1.0E+01
1.0E+00
55
65
75
85
95
Temperature (°C)
Bias Conditions: Vd=4.0V, Id=240 mA
Typical Application
RF OUT
IF In
2 GHz
XP1005
XU1006-QB
Coupler
37.0-39.5 GHz
Mixer
X
Buffer
X2
LO(+2.0dBm)
17.5-18.75 GHz (USB Operation)
19.5-20.75 GHz (LSB Operation)
Mimix Broadband MMIC-based 35.0-45.0 GHz Transmitter Block Diagram
(Changing LO and IF frequencies as required allows design to operate as high as 42 GHz)
Mimix Broadband's 36.0-42.0 GHz XU1006-QB GaAs Transmitter can be used in saturated radio applications and linear modulation
schemes up to 128 QAM.The transmitter can be used in upper and lower sideband applications from 36.0-42.0 GHz.
Page 7 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
App Note [3] USB/LSB Selection -
USB
LSB
For Upper Side Band operation (USB):
With IF1 and IF2 connected to the
direct port (0º) and coupled port (-90º)
respectively as shown in the diagram,
the USB signal will reside on the
input port.The isolated port must be
loaded with 50 ohms.
Direct Port
Coupled Port
For Lower Side Band operation (LSB):
With IF1 and IF2 connected to the
direct port (0º) and coupled port (-90º)
respectively as shown in the diagram,
the LSB signal will reside on the isolated
port.The input port must be loaded
with 50 ohms.
2F1
2F2
An alternate method of Selection of USB or LSB:
LSB
USB
In Phase Combiner
In Phase Combiner
-90o
-90o
IF2
IF1
IF2
IF1
Factory Automation and Identification
Mimix
Designator
Package
Type
Number of
leads offered
W Tape
Width
P1 Component P0 Hole
Reel
Diameter
Units
per Reel
Pitch
Pitch
-QB
QFN (7x7mm)
16mm
28
12mm
4mm
329mm (13in)
1000
Tape and Reel Packaging per the following conditions:
Tape Width:
16 mm
Tape Pitch (part to part):
Component Orientation:
Reel Diameter:
12 mm
Parts are to be oriented with the PIN 1 closest to the tape's round sprocket holes on the tape’s trailing edge.
329 mm (13 inch)
Note:Tape and Reel packaging is ordered with a -000T suffix. Package is available in 500 unit reels through designated sales channels.
Minimum order quantities should be discussed with your local sales representative.
Page 8 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
36.0-42.0 GHz GaAsTransmitter
SMT, 7x7 mm
April 2009 - Rev 15-Apr-09
U1006-QB
CAUTION! - Mimix Broadband MMIC Products contain gallium arsenide (GaAs) which can be hazardous to the human body and the
environment. For safety, observe the following procedures:
Do not ingest.
Do not alter the form of this product into a gas, powder, or liquid through burning, crushing, or chemical processing as these
by-products are dangerous to the human body if inhaled, ingested, or swallowed.
Observe government laws and company regulations when discarding this product.This product must be discarded in
accordance with methods specified by applicable hazardous waste procedures.
Life Support Policy - Mimix Broadband's products are not authorized for use as critical components in life support devices or
systems without the express written approval of the President and General Counsel of Mimix Broadband. As used herein: (1) Life
support devices or systems are devices or systems which, (a) are intended for surgical implant into the body, or (b) support or sustain
life, and whose failure to perform when properly used in accordance with instructions for use provided in the labeling, can be
reasonably expected to result in a significant injury to the user. (2) A critical component is any component of a life support device or
system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its
safety or effectiveness.
Package Attachment - This packaged product from Mimix Broadband is provided as a rugged surface mount package compatible
with high volume solder installation. Vacuum tools or other suitable pick and place equipment may be used to pick and place this
part. Care should be taken to ensure that there are no voids or gaps in the solder connection so that good RF, DC and ground
connections are maintained. Voids or gaps can eventually lead not only to RF performance degradation, but reduced reliability and
life of the product due to thermal stress.
Reflow Profile
SnPb
Pb Free
Ramp Up Rate
3-4 ºC/sec
60-120 sec @ 140-160 ºC
60-150 sec
240 ºC
3-4 ºC/sec
Activation Time and Temperature
Time Above Melting Point
Max Peak Temperature
Time Within 5 ºC of Peak
Ramp Down Rate
60-180 sec @ 170-200 ºC
60-150 sec
265 ºC
10-20 sec
10-20 sec
4-6 ºC/sec
4-6 ºC/sec
Mimix Lead-Free RoHS Compliant Program - Mimix has an active program in place to meet customer and governmental
requirements for eliminating lead (Pb) and other environmentally hazardous materials from our products. All Mimix RoHS compliant
components are form, fit and functional replacements for their non-RoHS equivalents. Lead plating of our RoHS compliant parts is
100% matte tin (Sn) over copper alloy and is backwards compatible with current standard SnPb low-temperature reflow processes as
well as higher temperature (260°C reflow) “Pb Free” processes.
Ordering Information
Part Number for Ordering Description
XU1006-QB-0N00
XU1006-QB -0N0T
XU1006-QB -EV1
Ni/Au plated RoHS compliant 7x7 28L surface mount package in bulk quantity
Ni/Au plated RoHS compliant 7x7 28L surface mount package in tape and reel
XU1006-QB evaluation board
Caution: ESD Sensitive
Appropriate precautions in handling, packaging
and testing devices must be observed.
Proper ESD procedures should be followed when handling this device.
Page 9 of 9
Mimix Broadband, Inc., 10795 Rockley Rd., Houston,Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Characteristic Data and Specifications are subject to change without notice. ©2009 Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
厂商 型号 描述 页数 下载

ETC

 		XU1-N18PP340 REFLEXLICHTTASTER VERDRAHTET RLS INLINE\n[ REFLEXLICHTTASTER VERDRAHTET RLS INLINE ] 4 页

ETC

 		XU1-N18PP340W REFLEXLICHTTASTER VERDRAHTET RLS 90\n[ REFLEXLICHTTASTER VERDRAHTET RLS 90 ] 4 页

MIMIX

 		XU1000 17.0-27.0 GHz的砷化镓MMIC变送器[ 17.0-27.0 GHz GaAs MMIC Transmitter ] 5 页

MIMIX

 		XU1000-BD-000W [ Up Converter, ROHS COMPLIANT, PLASTIC, DIE-5 ] 5 页

MIMIX

 		XU1001 33.0-40.0 GHz的砷化镓MMIC变送器[ 33.0-40.0 GHz GaAs MMIC Transmitter ] 8 页

MIMIX

 		XU1001-BD 33.0-40.0 GHz的砷化镓MMIC变送器[ 33.0-40.0 GHz GaAs MMIC Transmitter ] 8 页

MIMIX

 		XU1001-BD-000V 33.0-40.0 GHz的砷化镓MMIC变送器[ 33.0-40.0 GHz GaAs MMIC Transmitter ] 8 页

MIMIX

 		XU1001-BD-000W 33.0-40.0 GHz的砷化镓MMIC变送器[ 33.0-40.0 GHz GaAs MMIC Transmitter ] 8 页

MIMIX

 		XU1001-BD-EV1 33.0-40.0 GHz的砷化镓MMIC变送器[ 33.0-40.0 GHz GaAs MMIC Transmitter ] 8 页

MIMIX

 		XU1002 18.0-25.0 GHz的砷化镓MMIC变送器[ 18.0-25.0 GHz GaAs MMIC Transmitter ] 8 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.273834s
