PHOTOTRANSISTOR OPTICAL
INTERRUPTER SWITCH
QVE00832
PACKAGE DIMENSIONS
0.551 (14.00)
+
D
+
C
0.236 (6.00)
L
E
0.020 (.50)
0.197
(5.00)
C
L
C (OPTICAL)
L
0.394 (10.00)
(2X)
0.100 (2.50)
0.295 (7.50)
SCHEMATIC
FEATURES
0.197 (5.00)
MIN (4X)
0.027 (.70)
(2X)
• No contact switching
• 5mm wide slot
0.400
1
4
(10.16)
(2X) (NOM)
0.260
(6.60)
KNOB
Ø0.026 (.66)
• 0.5 mm aperture width
• Opaque black plastic housing
• Locating knobs on housing base
for accurate mounting
• Transistor Output
0.092 (2.35)
C
PINS
0.020 (.51) (4X)
SQ. (TYP)
L
2
3
2
1
3
4
C
L
0.205 (5.20)
0.100 (2.54) (2X)
(TYP)
NOTES
PIN 1 ANODE
PIN 3 COLLECTOR
PIN 4 EMITTER
PIN 2 CATHODE
1. Derate power dissipation linearly 1.67 mW/°C above 25°C.
2. RMA flux is recommended.
NOTES:
3. Methanol or isopropyl alcohols are recommended as
cleaning agents.
4. Soldering iron tip 1/16” (1.6mm) from housing.
1. Dimensions for all drawings are in inches (millimeters).
2. Tolerance of .010 (.25) on all nonꢀnominal dimensions
unless otherwise specified.
(T = 25°C unless otherwise specified)
ABSOLUTE MAXIMUM RATINGS
A
Parameter
Operating Temperature
Storage Temperature
Soldering Temperature (Iron)(2,3,4)
Soldering Temperature (Flow)(2,3)
EMITTER
Symbol
TOPR
Rating
Units
°C
ꢀ55 to +100
ꢀ55 to +100
240 for 5 sec
260 for 10 sec
TSTG
°C
TSOLꢀI
TSOLꢀF
°C
°C
Continuous Forward Current
Reverse Voltage
IF
60
6
mA
V
VR
PD
Power Dissipation(1)
SENSOR
150
mW
CollectorꢀEmitter Voltage
EmitterꢀCollector Voltage
Collector Current
VCEO
VECO
IC
30
4.5
20
V
V
mA
mW
Power Dissipation(1)
PD
150
2001 Fairchild Semiconductor Corporation
DS300257
1/3/02
1 OF 4
www.fairchildsemi.com
