12V 75Ah
XTV12750
XTV 12750 is a general battery up to 12 years expected life in
standby service or more than 400 cycles at 100% discharge in
cycle service . XTV!has a wider operating temperature range,
which makes them more suitable for the systems in harsh
Specification
Cells Per Unit
conditions.
6
Voltage Per Unit
12
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
75 Ah @ 10hr-rate to 1.80 V per cell @25 (77
Approx. 29.5 kg(65.04 lbs)
800A(5sec)
)
Approx. 6.5m
Discharge: -20 ~50
Charge: -20 ~50
Storage: -15 ~40
(-4 ~122
)
(-4 ~122
(5 ~104
)
)
Nominal Operating Temperature Range 25
3
(77
5 )
Float Charging Voltage
Recommended Maximum Charging
Current Limit
13.5 to 13.8 VDC/unit Average at 25 (77
22.5A
)
Equalization and Cycle Service
Self Discharge
14.4 to 15.0 VDC/unit Average at 25 (77
)
CSB-manufactured
CSB Batteries can be stored for more than 6 months at
25 (77 ). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
I2-Thread lead alloy recessed terminal to accept M6 bolt
PP (UL 94-V0/File E50955)*Flammability resistance
of (UL 94-HB/File E216959) can be available upon request.
VRLA batteries are UL-
recognized components
under UL924 and UL1989.
Terminal
Container Material
CSB is also certified by
ISO 9001 and ISO 14001.
Dimensions :
Unit: mm (inch)
Overall Height (H)
214.3 2.5 (8.44 0.1)
Container height (h)
Length (L)
Width (W)
169 2 (6.66 0.08)
211.3 2.5 (8.32 0.1) 308.7 2.5 (12.15 0.1)
ˉʿ˄ˇʵʿ˄ˈˉ
ʵ
3
1
2
Constant Current Discharge Characteristics Unit:A (25 ,77
)
F.V/Time 5MIN
10MIN 15MIN 30MIN
1HR
54.6
53.5
52.9
51.4
49.5
46.2
2HR
32.4
31.7
31.5
30.6
29.2
27.4
3HR
22.3
22.1
21.8
21.2
20.8
19.7
4HR
17.1
17.0
16.9
16.6
16.3
15.4
5HR
14.1
14.0
13.9
13.7
13.4
12.9
8HR
9.39
9.35
9.32
9.16
9.00
8.68
10HR
7.89
7.73
7.67
7.57
7.50
7.14
20HR
4.09
4.07
4.05
4.00
3.93
3.78
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
285
252
235
208
189
156
197
184
176
163
147
131
151
144
140
133
123
107
91.6
90.0
88.4
84.5
79.7
72.9
Constant Power Discharge Characteristics Unit:W (25 ,77
)
F.V/Time 5MIN
10MIN 15MIN 30MIN
1HR
606
598
596
583
563
531
2HR
361
356
354
345
331
314
3HR
256
253
251
245
240
228
4HR
201
197
195
193
188
178
5HR
165
163
162
161
156
149
8HR
111
110
109
107
106
102
10HR
92.4
91.6
90.8
90.0
89.2
85.3
20HR
47.9
47.4
47.1
46.9
46.2
44.8
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
2671
2469
2385
2237
1971
1677
1993
1895
1839
1726
1602
1424
1604
1557
1539
1444
1322
1165
993
982
973
942
898
834
Ratings are preliminary and subject to change.
