12V 85Ah
XTV12850
XTV 12850 is a general battery up to 12 years expected life in
standby service or more than 400 cycles at 100% discharge in
cycle service . XTV!has a wider operating temperature range,
which makes them more suitable for the systems in harsh
conditions.
Specification
Cells Per Unit
6
Voltage Per Unit
Capacity
12
85 Ah @
10hr-rate to 1.80V per cell @25 (77
)
Weight
Approx. 31.2 kg(68.78 lbs)
800A(5sec)
Approx. 6.5m
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Discharge: -20 ~50
Charge: -20 ~50
Storage: -15 ~40
(-4 ~122
(-4 ~122
(5 ~104
)
)
)
Nominal Operating Temperature Range 25
3
(77
5 )
Float Charging Voltage
Recommended Maximum Charging
Current Limit
13.5 to 13.8 VDC/unit Average at 25 (77
25.5A
)
Equalization and Cycle Service
Self Discharge
14.4 to 15.0 VDC/unit Average at 25 (77
)
CSB-manufactured
CSB Batteries can be stored for more than 6 months at
25 (77 ). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
VRLA batteries are UL-
recognized components
under UL924 and UL1989.
Terminal
Container Material
I2-Thread lead alloy recessed terminal to accept M6 bolt
PP (UL 94-V0/File E50955)*Flammability resistance
of (UL 94-HB/File E216959) can be available upon request.
CSB is also certified by
ISO 9001 and ISO 14001.
Dimensions :
Unit: mm (inch)
Overall Height (H)
217.6 2.5 (8.57 0.1)
Container height (h)
214.6 2.5 (8.45 0.1)
Length (L)
343 2.5 (13.5 0.1)
Width (W)
170 2 (6.69 0.08)
(http://www.csb-battery.com)
Constant Current Discharge Characteristics Unit:A (25 ,77
)
F.V/Time 5MIN
10MIN 15MIN 30MIN
1HR
62.0
60.6
59.9
58.3
56.1
52.3
2HR
36.8
36.0
35.7
34.6
33.2
31.0
3HR
25.3
25.1
24.8
24.1
23.6
22.4
4HR
19.4
19.3
19.1
18.7
18.5
17.5
5HR
16.1
15.9
15.8
15.6
15.3
14.5
8HR
10.7
10.6
10.5
10.3
10.2
9.85
10HR
8.90
8.80
8.78
8.58
8.50
8.10
20HR
4.64
4.61
4.59
4.54
4.46
4.28
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
323
286
266
236
215
178
224
209
200
185
166
148
170
163
159
151
139
121
103
101
99.4
95.6
90.1
82.7
Constant Power Discharge Characteristics Unit:W (25 ,77
)
F.V/Time 5MIN
10MIN 15MIN 30MIN
1HR
687
678
676
662
638
601
2HR
409
404
401
391
376
356
3HR
290
287
285
278
272
259
4HR
227
224
223
219
213
203
5HR
187
185
183
182
178
169
8HR
125
124
123
122
120
116
10HR
104
103
102
101
20HR
54.3
53.7
53.4
53.2
52.4
50.8
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
3027
2800
2704
2536
2234
1901
2260
2148
2085
1956
1816
1615
1819
1765
1745
1636
1499
1320
1125
1113
1102
1068
1017
945
100
96.6
Ratings are preliminary and subject to change.
