Preliminary
XTC7005
• Temperature Compensated Crystal Oscillator
• Miniature SMD Package
• Excellent Frequency Stability
• Low Phase Noise
16.36900 MHz
TCXO
• Complies with Directive 2002/95/EC (RoHS)
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
F
Nominal Frequency
16.36900
MHz
O
Frequency Tolerance after Reflow
Storage Temperature Range in Tape and Reel
Operating Temperature Range
±2 ppm maximum @ 25 ±3 °C
-40
+85
+85
3.00
°C
°C
V
-40
2.70
0.8
V
Power Supply Voltage
2.85
DD
V
Output Voltage with 10 pF || 10 KΩ Load
Output Waveform
P-P
Clipped Sinewave
Duty Cycle
40
%
60
I
Power Supply Current
2.0
mA
DD
Frequency Stability versus:
Temperature, -30 to +85 °C
Temperature, -40 to -30 °C
Load Variation, 10 pF || 10 KΩ ±10%
Supply Voltage, 2.85 V ±5%
Frequency Step, df/f
±0.5
±2.0
±0.2
±0.2
±2.5
±2.5
±0.1
±0.6
2.0
ppm
ppm
ppm
ppm
ppb
Short Term Drift, df/f/s
ppb/s
ppm/°C
ppm
Frequency Slope, one measurement every 2 °C, -30 to +85 °C
Static Temperature Hysteresis
Start Up Time, 90% of Final RF level in V
ms
P-P
Harmonics
-5.0
-23
dBc
SSB Phase Noise @ 0.1 Hz Carrier Offset
SSB Phase Noise @ 1 Hz Carrier Offset
SSB Phase Noise @ 10 Hz Carrier Offset
SSB Phase Noise @ 100 Hz Carrier Offset
SSB Phase Noise @ 1 kHz Carrier Offset
SSB Phase Noise @ 10 kHz Carrier Offset
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
ppb/G
ppm
-53
-78
-93
-103
-108
2
G Sensitivity, 3 axes, 30 to 1500 Hz, +25 °C, V = 3 V
DD
Aging @ 25 °C
±1.0
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
1000
units
Line1: 7005 Line2: YWWS
Notes:
1. The design, manufacturing process, and specifications of this device are subject to change without notice.
2. CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
www.RFM.com E-mail: info@rfm.com
©2009-2011 by RF Monolithics, Inc.
Page 1 of 3
XTC7005 - 4/4/11
