XTC7003P
• Temperature Compensated Crystal Oscillator
• Miniature SMD Package
• Excellent Frequency Stability
• Low Phase Noise
12.80000 MHz
TCXO
• Complies with Directive 2002/95/EC (RoHS)
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
F
Nominal Frequency
12.80000
MHz
O
Frequency Tolerance after Reflow
Storage Temperature Range in Tape and Reel
Operating Temperature Range
±2 ppm maximum @ 25 ±2 °C
-40
+85
+85
3.30
°C
°C
V
-40
2.70
0.8
V
Power Supply Voltage
3.00
DD
V
Output Voltage with 10 pF || 10 KΩ Load
Output Waveform
P-P
Clipped Sinewave
I
Power Supply Current
3.0
mA
DD
Frequency Stability versus:
Temperature, -30 to 70 °C, Referenced to 25 °C
Temperature, -40 to 85 °C, Referenced to 25 °C
Load Variation, 10 pF || 10 KΩ ±10%
Supply Voltage, 3.00 V ±5%
±1
±3
ppm
ppm
ppm
ppm
ms
±0.2
±0.2
2.0
Start Up Time, 90% of Final RF level in V
P-P
Harmonics
-5.0
-135
±1.0
dBc
SSB Phase Noise @ 10 kHz Carrier Offset
Aging @ 25 °C
dBc/Hz
ppm
units
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
1000
Line1: 003P Line2: YWWS
Pin Connections
Connection
Ground
Terminals
1
2
3
4
Ground
TCXO Output
V
DD
