XTC7001
• Temperature Compensated Crystal Oscillator
• Minature SMD 5.0 x 3.2 x 1.4 mm Package
• Good Frequency Stability
• Low Phase Noise
• Complies with Directive 2002/95/EC (RoHS)
18.41400 MHz
TCXO
P
b
SM5032-8 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
MHz
F
Nominal Frequency
18.41400
O
Storage Temperature Range in Tape and Reel
Operating Temperature Range
Power Supply Voltage
-40
-40
+85
+85
3.15
°C
°C
V
V
2.85
0.8
3.00
DD
V
V
P-P
Output Voltage with Load 10 pF || 10 KΩ
Power Supply Current
OUT
l
2.0
mA
DD
Output Waveform
Clipped Sinewave
Frequency Tolerance
±2.0 ppm max @ 25 °C ±3 °C
Frequency Stability versus:
Temperature, -40 to 85 °C
Load Variation, 10 pF ||10 KΩ ±10%
Supply Voltage, 3 V ±5%
±2.5
±0.2
±0.2
ppm
ppm
ppm
ms
Start Up Time, 90% of final RF level in V
3.0
-7.0
P-P
Harmonics
dBc
units
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
1000
Line1: 7001 Line2: YWWS
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
The design, manufacturing process, and specifications of this device are subject to change without notice.
www.RFM.com E-mail: info@rfm.com
©2009-2010 by RF Monolithics, Inc.
Page 1 of 3
XTC7001 - 2/4/10
