Preliminary
XTC7006G
• Temperature Compensated Crystal Oscillator
• Ultra-miniature 2.5 x 2.0 x 0.8 mm Package
• Excellent Frequency Stability
• Low Phase Noise
26.000000 MHz
TCXO
• Complies with Directive 2002/95/EC (RoHS)
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
F
Nominal Frequency
26.000000
MHz
O
Frequency Tolerance after Reflow
Storage Temperature Range in Tape and Reel
Operating Temperature Range
±2 ppm maximum @ 25 ±3 °C
+85
-40
-30
°C
°C
V
+85
V
Power Supply Voltage Range
Output Voltage with 10 pF || 10 KΩ Load
Output Waveform
2.66
0.8
2.80
2.94
CC
V
P-P
Clipped Sinewave
I
Power Supply Current
2.0
mA
CC
Frequency Stability versus:
Temperature, -30 to 85 °C
Load Variation, 10 pF || 10 KΩ ±10%
Supply Voltage, 2.8 V ±5%
±0.5
±0.2
±0.3
2.0
ppm
ppm
ppm
Start Up Time, 90% of Final RF Level in V
ms
P-P
Harmonics
-5.0
dBc
Frequency Slope, measured at least every 2 °C, -20 to +75 °C
SSB Phase Noise @ 1 kHz Carrier Offset
Aging @ 25 °C
±0.05
-130
±1.0
ppm/°C
dBc/Hz
ppm/yr
units
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization
1000
3R
Pin Connections
Connection
Ground
Terminals
1
2
3
4
Ground
TCXO Output
V
DD
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1. The design, manufacturing process, and specifications of this device are subject to change without notice.
www.RFM.com E-mail: info@rfm.com
©2010-2011 by RF Monolithics, Inc.
Page 1 of 3
XTC7006G - 4/4/11
