XTC7009G
• Temperature Compensated Crystal Oscillator
• Ultra-miniature 2.5 x 2.0 x 0.8 mm Package
• Excellent Frequency Stability
• Low Phase Noise
16.36800 MHz
TCXO
• Complies with Directive 2002/95/EC (RoHS)
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
F
Nominal Frequency
16.36800
MHz
O
Frequency Tolerance after Reflow
Storage Temperature Range in Tape and Reel
Operating Temperature Range
±2 ppm maximum @ 25 ±3 °C
+85
-40
-40
°C
°C
V
+85
V
Power Supply Voltage Range
Output Voltage with 10 pF || 10 KΩ Load
Output Waveform
2.70
0.8
2.85
3.00
CC
V
P-P
Clipped Sinewave
Duty Cycle
40
%
60
I
Power Supply Current
1.5
mA
CC
Frequency Stability versus:
Temperature, -30 to 85 °C
Temperature, -40 to 30 °C
Load Variation, 10 pF || 10 KΩ ±10%
Supply Voltage, 2.85 V ±5%
Frequency Step, df/f
±0.5
±2.0
±0.2
±0.2
±2.5
±2.5
2.0
ppm
ppm
ppm
ppm
ppb
Short Term Drift, df/f/s
ppb/s
ms
Start Up Time, 90% of Final RF Level in V
P-P
Harmonics
-5.0
±0.1
±0.6
-23
dBc
Frequency Slope, measured at least every 2 °C, -30 to +85 °C
Static Temperature Hysteresis
ppm/°C
ppm
SSB Phase Noise @ 0.1 Hz Carrier Offset
SSB Phase Noise @ 1 Hz Carrier Offset
SSB Phase Noise @ 10 Hz Carrier Offset
SSB Phase Noise @ 100 Hz Carrier Offset
SSB Phase Noise @ 1 kHz Carrier Offset
SSB Phase Noise @ 10 kHz Carrier Offset
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
ppb/G
ppm/yr
units
-53
-78
-93
-103
-108
2
G Sensitivity, 3 axes, 30 to 1500 Hz, +25 °C, V = 3V
DD
Aging @ 25 °C
±1.0
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization
1000
3S
Notes:
1. The design, manufacturing process, and specifications of this device are subject to change without notice.
2. CAUTION: Electrostatic sensitive device. Observe handling precautions.
