Preliminary
XTC7010
• Temperature Compensated Crystal Oscillator
• Miniature 3.2 x 2.5 mm Package
• Excellent Frequency Stability
• Low Phase Noise
15.00000 MHz
TCXO
• Complies with Directive 2002/95/EC (RoHS)
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
fO
Nominal Frequency
15.00000
MHz
Frequency Tolerance after Reflow
Storage Temperature Range in Tape and Reel
Operating Temperature Range
±2 ppm maximum @ 25 ±2 °C
+85
-40
-40
°C
°C
+85
VDD
Power Supply Voltage
2.66
0.5
2.80
2.94
V
VP-P
Out Voltage with 10 pF || 10 K Load
Output Waveform
Clipped Sinewave
IDD
Power Supply Current
2.0
mA
Frequency Stability versus:
Temperature, -40 to 85 °C
±2.5
±0.2
±0.2
2.0
ppm
ppm
Load Variation, 10 pF || 10 K±10%
Supply Voltage, 2.80 V ±5%
Start Up Time, 90% of Final RF level in VP-P
ppm
ms
Harmonics
-5.0
-130
±1.0
dBc
SSB Phase Noise @ 1 kHz Carrier Offset
Aging @ 25 °C
dBc/Hz
ppm/yr
units
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
1000
Line 1: 7010 Line 2: YWWS
Pin Connections
Connection
Ground
Terminals
1
2
3
4
Ground
TCXO Output
VDD
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1. The design, manufacturing process, and specifications of this device are subject to change without notice.
www.RFM.com E-mail: info@rfm.com
©2009-2011 by RF Monolithics, Inc.
Page 1 of 3
XTC7010 - 12/12/11
