Preliminary
XTC7006-1
• Temperature Compensated Crystal Oscillator
• Miniature SMD Package
• Initial Tolerance ±2 ppm
• Low Phase Noise
• Complies with Directive 2002/95/EC (RoHS)
26.00000 MHz
TCXO
P
b
4-Terminal SMD Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
MHz
°C
F
Nominal Frequency
26.00000
O
Storage Temperature Range in Tape and Reel
Operating Temperature Range
Power Supply Voltage
-40
-30
+85
+85
3.15
°C
V
2.85
0.8
3.0
V
DD
V
V
Output Voltage with 10 pF ||10 KΩ Load
Output Waveform
OUT
P-P
Clipped Sinewave
I
Power Supply Current
2.0
mA
DD
Frequency Tolerance after Reflow
Frequency Stability versus:
±2 ppm maximum @ 25 ±3 °C
Temperature, -30 to 85 °C
±2.5
ppm
ppm
ppm
Load Variation, 10 pF || 10 KΩ ±10%
Supply Voltage, 3.00 V ±5%
Frequency Slope (one measurement at least every 2 °C)
±0.2
±0.2
±0.3 ppm/°C maximum, -30 to 80 °C
2.0
Start Up Time, 90% of Final RF level in V
ms
dBc
P-P
Harmonics
-7.0
Static Temperature Hysteresis
Aging at 25 °C
±0.6
ppm
±1.0
ppm/yr
dBc/Hz
units
Phase Noise @ 1 kHz carrier offset
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
-130
1000
Line1: 70061 Line2: YWWS
Pin Connections
Connection
Ground
Terminals
1
2
3
4
Ground
TCXO Output
V
DD
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
The design, manufacturing process, and specifications of this device are subject to change without notice.
www.RFM.com E-mail: info@rfm.com
©2009-2011 by RF Monolithics, Inc.
Page 1 of 3
XTC7006-1 4/4/11
